Additional Specifications |
Top Burner Rating (Front) |
Nat: 25,000 BTUs / LP: 24,000 BTUs |
Top Burner Rating (Rear) |
18,000 BTUs |
Simmer Burner Rating |
600 BTUs |
Bake Element Rating |
3500W (2500W Inner / 1000W Outer) |
Small Oven Bake Element Rating |
2800W |
Broiler Rating |
5000W (2500W Inner / 2500W Outer) |
Large Oven Convection Element Rating |
2800W |
Operating Gas Pressure |
Nat: 5" WC / LP: 10" WC |
Gas Line Size |
3/4" |
Installation Clearance (Below Counter) |
0" Side Cabinet | 0" Back Wall |
Installation Clearance (Above Counter) |
6" Side Cabinet |
Door Clearance |
20" from the front of the door |
Electrical Specifications |
Volts: 240V, Amps: 50A, Frequency: 60Hz Note: Unit must be on a Non-GFI, dedicated outlet |
Dimensions |
Overall Width: 47 7/8" Overall Depth: 26 1/2" Overall Height: 36" Large Oven Interior: 26 1/4"W x 20"D x 16 5/8"H Small Oven Interior: 14 1/8"W x 20"D x 16 5/8"H |
Backguard Options |
BG648DF |
6" Backguard for 48" Dual Fuel Series |
SDHS48DF |
24" High Shelf for 48" Dual Fuel Series |
Knob & Painted Body Side Options |
Total Knobs |
8 |
SIDES-C |
Add Painted Sides (All colors) |
KN-BLK |
Standard Black Knob (Ordered with the unit) |
KN-C |
Knob: Standard 190 RAL Color |
BZ-C |
Bezel: Standard 190 RAL Color |
KN-CF |
Knob: Spec Finish (Matte RAL, Textured RAL, or Prec Metals) |
KN-PLT |
Knob: Plated Trim |
Plated Trim Options |
Colors |
Antique Brass, Brushed Brass, Polished Brass, Antique Copper, Brushed Copper, Polished Copper, Chrome, Oil Rubbed Bronze & Pewter |
